Technical Specifications

Cutting diameter: 130–250 mm, adjustable via PLC
Cutting length:50–380 mm, adjustable via PLC
Maximum log length: 2,750 mm, adjustable via PLC
Log lengths: Adjustable via PLC
Cutting speed: Manually adjusted according to log diameter, thickness and cutting length
Maximum stable operation speed: Up to 20 cuts/min for logs below 210 mm diameter and cutting lengths of 50–220 mm
For cutting lengths above 220 mm: Automatic speed adjustment to approximately 10 cuts/min
Automatic blade sharpening
Automatic log loading/pick-up table
Log storage rack with automatic feeding
Automatic waste/reject removal via mechanical pusher (if using the push hand)
Electrical connection: 3 × 400 V, 40 A
Compressed air: 0.6 MPa
Machine dimensions: 3,500 × 2,500 × 2,000 mm
Weight: Approximately 3,000 kg (2 parts, cutter and the mechanical pusher)
Country of manufacture: China

Machine data
Machine type:Cutting machine
Manufacturer:Dacoo group
Model:TZ-JRT-30B-2800
Machine number:TZ-JRT-30B-2800
Year of construction:2020
Condition:ready for operation (used)
Functionality:fully functional
